Fröling SP Dual compact Installation Instructions Manual page 33

Item Quant
ity
1 1 Fibre-glass seal for induced draught fan
2 1 Induced draught fan Ø 180
3 1 Thermal insulation for induced draught unit
housing
4 1 Thermal insulation for back panel
5 13 Tension spring
6 1 Back panel
7 2 Cover plate for ID fan
8 1 Cover plate, boiler return
9 1 Cable duct cover
10 1 Side panel, right
11 1 Thermal insulatio pellet flange
12 1 Cover plate pellet flange
13 1 Floor insulation
14 1 Insulating door mounting
15 1 Torque support for actuators
16 1 Servo-motor
17 1 Cover plate for air control
18 1 Insulated door
19 1 Door pin
20 1 7" Touch control
1. For firewood boilers with pellet flange
M1820921_en | Installation instructions Dual fuel boiler SP Dual compact
Description
1)
1)
Item Quant
ity
21 2 Plugs, plastic
22 1 Cover plate with door contact switch
23 1 Stop for WOS lever
24 1 WOS lever
25 1 Bracket for controller box
26 1 Side panel, left
27 1 Cover plate WOS lever
28 1 Thermal insulation for top of boiler
29 1 Controller box, complete
30 1 Thermal insulation for cleaning cover
31 1 Adjusting screw
32 1 Thermal insulation for reversing chamber
cover
33 1 Controller cover
34 1 Cover
35 1 Flue gas temperature sensor bushing
36 1 Flue gas temperature sensor
37 1 Flue gas temperature sensor wing screw
38 1 Lambda probe bushing
39 1 Lambda probe adaptor
40 1 Lambda probe
Installation | 6
Description
33
