4 | Technical information

4 Technical information

4.1 Dimensions SP Dual compact

B1
B2
B4
Dimensi
on
L1
Length, pellet unit
L2
Length, firewood boiler
L3
Total length incl. induced draught fan
B1
Total width including WOS lever
B2
Width, firewood boiler
B3
Width, pellet unit
B4
SP Dual width
B5
Distance between flue gas pipe connection and side of boiler
B6
Distance between safety heat exchanger connection and side of boiler
B7
Distance between safety heat exchanger connections
B8
Distance between flow connection and side of boiler
B9
Distance between return connection and side of boiler
B10
Distance between drainage connection and side of boiler
H1
Height, pellet unit
H2
Height of flue gas pipe connection
H3
Total height incl. flue gas nozzle
H4
Height of hose line connection
H5
Height, safety heat exchanger connection
H6
Height, drainage connection
H7
Height, flow connection
1. When using the optional flue pipe nozzle for low chimney connections
18
B3
Description
1)
L1
L2
L3
M1820921_en | Installation instructions Dual fuel boiler SP Dual compact
B5
B6
B7
B8
B9
B10
Unit
15-20
mm
855
1000
1080
1145
685
315
1000
665
430
65
570
150
890
1340
1300
1395
1255
1040
150
1055
