Daikin Modular L Smart Service Manual page 66

ESIE19-06 | Part 5. Appendix
How to select the optimal Ventilation Speed
The fine tuning of the Ventilation Speed can be done properly modifying the following parameters:
• Initial fan speed: High or Ultra-High
• Supply fan step setting: Step 1 to 15
• Exhaust fan step setting: Step 1 to 15
These parameters can be accessed following the procedure The Configuration Service Settings
Both Supply and Return Fans have an optimal speed value, described in term of RPM (Revolution per Minute), that can be retrieved directly from the DAE Unit Selection Software report,
as shown below:
3) Fan Supply
Model
Type
Material
Quantity
External Static Pressure
Internal Static Pressure
Total Static Pressure
Dynamic Pressure
Flow Design
Rotation Speed Work • Max
Efficiency
Shaft Power
Electrical Power Input
Power Class • PMREF (EN13053)
SFPv Class • SFPv (EN13053)
3) Fan Return
Model
Type
Material
Quantity
External Static Pressure
Internal Static Pressure
Total Static Pressure
Dynamic Pressure
Flow Design
Rotation Speed Work • Max
Efficiency
Shaft Power
Electrical Power Input
Power Class • PMREF (EN13053)
SFPv Class • SFPv (EN13053)
Optimal RPM values for Supply and Return (Exhaust) Fans
Provided the Unit Size is known, you can proceed to set the correspondent Supply/Return Fan step on the BRC controller, according to the following Speed-selection Tables (Make sure
to consider "Heat recovery operation" rpm).
If you do not have the unit selection from Daikin tool software, please check individual unit size performances from
Speed-selection tables
In order to select the correct step for the Supply and Return Fan it is necessary to:
• Choose the table whose Unit Size number equals the Unit Size provided in the DAE Unit Selection software report.
• Identify the Supply/Return Fan steps by choosing, from H(high) column, the steps whose RPM values are the closest to the Supply/Return Fan RPM provided by DAE Unit Selection
software report.
• Set the selected step values on the controller by going to the path Service Settings
- 19(29)-2- Selected_Step_Supply_Fan, for the Supply Fan Step, from 01 to 15
- 19(29)-3- Selected_Step_Return_Fan, for the Return Fan Step, from 01 to 15
• If both Supply and Return Fan RPM are not present in the column H, but they appear in UH (ultra high) one, then:
• Set the Initial Fan Speed to UltraHigh by going to the path Service Settings
• Set the selected steps as in point 3.
Page 66
Modular L Smart
→
K3G190RD4503
EC Centrifugal Fan
Composite
1x(Single Fan)
100 Pa
183 Pa
283 Pa
10 Pa
300 m³/h
2957 RPM • 4120 RPM
45.3%
0.07 kW
0.07 kW
P1 • 0.14 kW
SFP1 • 631 W/(m³/s)
K3G190RD4503
EC Centrifugal Fan
Composite
1x(Single Fan)
100 Pa
182 Pa
282 Pa
10 Pa
300 m³/h
2954 RPM • 4120 RPM
45.3%
0.07 kW
0.07 kW
P1 • 0.14 kW
SFP1 • 609 W/(m³/s)
→
Field Settings and set the following
→
Field Settings and modifying the default value from 17(27)-4-01(High) to 17(27)-4-02(UltraHigh)
Field Settings page, as shown in the List of Settings paragraph.
page 67 onwards.
5.1. Field setting
21/01/20 | Version 1.1
