Daikin Modular L Smart Service Manual page 73

ESIE19-06 | Part 5. Appendix
Nominal conditions
SFPv values are evaluated with F7 and M5 filter respectively for supply and return air side.
Factory configuration
Size 02
Supply
Volume Flow Rate ESP Volume Flow Rate
300 100
RPM
2889
17(27)-4-01
19(29)-2-07
Size 04
Supply
Volume Flow Rate ESP Volume Flow Rate
1200 100
RPM
2891
17(27)-4-02
19(29)-2-09
Size 06
Supply
Volume Flow Rate ESP Volume Flow Rate
2300 100
RPM
2816
17(27)-4-02
19(29)-2-09
"Field setting without preliminary selection": adjust fan speed according to in duct flow measurement, as explained in the previous pages.
21/01/20 | Version 1.1
Exhaust
ESP
300 100
RPM
2853
19(29)-3-04
Exhaust
ESP
1200 100
RPM
2913
19(29)-3-07
Exhaust
ESP
2300 100
RPM
2933
19(29)-3-07
Modular L Smart
Figure 5-6: Size 07
Airflow (m³/h)
Size 03
Supply
Volume Flow Rate ESP Volume Flow Rate
600 100
RPM
2360
17(27)-4-01
19(29)-2-07
Size 05
Supply
Volume Flow Rate ESP Volume Flow Rate
1500 100
RPM
2479
17(27)-4-02
19(29)-2-08
Size 07
Supply
Volume Flow Rate ESP Volume Flow Rate
3000 100
RPM
2504
17(27)-4-02
19(29)-2-08
Exhaust
ESP
600 100
RPM
2387
19(29)-3-04
Exhaust
ESP
1500 100
RPM
2529
19(29)-3-06
Exhaust
ESP
3000 100
RPM
2679
19(29)-3-09
5.1. Field setting
Page 73
