Smart Gateway - Daikin Modular L Smart Service Manual

ESIE19-06 | Part 2. Troubleshooting

2.4.1.4. Smart Gateway

1
11
Item
1
2
3
4
5
6
7
8
9
10
11
Page 38
Modular L Smart
2
10 9
Location Function
PE Ground connection
J8 PIN NL Main switch connection
J14 PIN 1463 Pin 14 connection X22A - pin 63 connection X5A
DAMP-OUT Damper actuator
PS4 Return fan dps
PS3 Supply fan dps
PS2 Return filter dps
PS1 Supply filter dps
FAN1 Supply air fan
FAN2 Return air fan
ACS IN Smart Gateway - control PCB connection
2.4. Component checklist
3 4
8 7
5
6
