Daikin Modular L Smart Service Manual page 67

ESIE19-06 | Part 5. Appendix
Step
Heat recovery operation
UH
01 2813
02 2895
03 2976
04 3054
SA Fan RPM
05 3132
setting
06 3209
(19(29)-2-...)
07 3287
08 3361
09 3450
EA Fan RPM
10 3546
setting
11 3635
(19(29)-3-...)
12 3728
13 3809
14 3898
15 3976
This table refers to indicated values subject to tolerances.
In order to adjust the desired airflow value based on measurement at site, while increasing rpm you will obtain more air flow and while decreasing rpm, you will reduce air flow. If needed,
kindly change fan speed to reach the target air flow.
Step
Heat recovery operation
UH
01 2356
02 2424
03 2492
04 2557
SA Fan RPM
05 2622
setting
06 2687
(19(29)-2-...)
07 2752
08 2814
09 2889
EA Fan RPM
10 2969
setting
11 3044
(19(29)-3-...)
12 3121
13 3190
14 3264
15 3329
Step
Heat recovery operation
UH
01 2103
02 2164
03 2225
04 2283
SA Fan RPM
05 2341
setting
06 2399
(19(29)-2-...)
07 2457
08 2513
09 2579
EA Fan RPM
10 2651
setting
11 2717
(19(29)-3-...)
12 2787
13 2848
14 2914
15 2972
This table refers to indicated values subject to tolerances.
In order to adjust the desired airflow value based on measurement at site, while increasing rpm you will obtain more air flow and while decreasing rpm, you will reduce air flow. If needed,
kindly change fan speed to reach the target air flow.
21/01/20 | Version 1.1
Supply fan
Bypass operation
H L UH
2343 1236 2943
2428 1332 3020
2521 1429 3098
2606 1528 3176
2691 1628 3254
2765 1725 3335
2843 1825 3413
2917 1917 3491
3002 2021 3579
3076 2125 3672
3139 2221 3761
3213 2317 3853
3280 2402 3942
3357 2495 4035
3420 2580 4120
Supply fan
Bypass operation
H L UH
1962 1035 2464
2033 1116 2529
2111 1196 2594
2182 1280 2659
2253 1364 2725
2315 1444 2793
2380 1528 2858
2442 1605 2923
2514 1692 2997
2576 1779 3075
2628 1860 3149
2690 1940 3227
2746 2012 3301
2811 2089 3379
2864 2160 3450
Supply fan
Bypass operation
H L UH
1752 924 2200
1815 996 2258
1884 1068 2316
1948 1143 2374
2012 1217 2432
2067 1289 2493
2125 1364 2551
2181 1433 2609
2244 1511 2676
2300 1588 2745
2347 1660 2812
2402 1732 2881
2452 1796 2947
2510 1865 3016
2557 1929 3080
Modular L Smart
ML Smart Size 02
Heat recovery operation
H L UH
2376 1336 3106
2480 1421 3170
2576 1510 3238
2661 1591 3302
2758 1677 3370
2843 1765 3434
2939 1851 3502
3024 1936 3566
3120 2043 3647
3209 2154 3734
3276 2254 3811
3350 2361 3895
3417 2458 3969
3491 2543 4046
3557 2621 4120
ML Smart Size 03 & Size 04 & Size 06
Heat recovery operation
H L UH
1990 1119 2601
2077 1190 2655
2157 1264 2711
2229 1333 2765
2309 1404 2822
2380 1478 2876
2461 1550 2933
2532 1621 2986
2613 1711 3054
2687 1804 3127
2743 1888 3191
2805 1977 3261
2861 2058 3323
2923 2129 3388
2979 2194 3450
ML Smart Size 05 & Size 07
Heat recovery operation
H L UH
1776 999 2322
1854 1062 2370
1926 1129 2421
1990 1190 2469
2062 1253 2519
2125 1320 2567
2197 1383 2618
2261 1447 2666
2333 1527 2726
2399 1610 2791
2449 1685 2849
2504 1765 2912
2554 1837 2967
2609 1901 3025
2659 1959 3080
Exhaust fan
Bypass operation
H L UH
2646 1667 2787
2723 1748 2861
2807 1831 2936
2881 1915 3010
2958 2002 3080
3019 2083 3151
3087 2166 3219
3148 2250 3290
3222 2340 3370
3286 2424 3454
3344 2501 3531
3412 2585 3615
3470 2662 3692
3537 2749 3779
3592 2823 3853
Exhaust fan
Bypass operation
H L UH
2216 1396 2334
2280 1464 2396
2350 1534 2458
2412 1604 2520
2477 1676 2579
2528 1744 2639
2585 1814 2695
2636 1884 2755
2698 1959 2822
2752 2030 2892
2800 2094 2957
2857 2164 3027
2906 2229 3092
2962 2302 3164
3008 2364 3226
Exhaust fan
Bypass operation
H L UH
1978 1246 2084
2036 1307 2139
2098 1369 2195
2154 1432 2250
2211 1497 2303
2257 1557 2356
2308 1619 2406
2353 1682 2459
2409 1749 2519
2457 1812 2582
2500 1870 2640
2551 1932 2702
2594 1990 2760
2644 2055 2825
2685 2110 2880
5.1. Field setting
H L
2292 1236
2363 1310
2440 1384
2511 1458
2588 1532
2659 1606
2736 1680
2804 1757
2884 1851
2961 1947
3029 2034
3093 2131
3154 2218
3219 2308
3280 2375
H L
1919 1035
1978 1097
2043 1159
2102 1221
2167 1283
2226 1345
2291 1407
2348 1472
2415 1550
2480 1631
2536 1703
2590 1784
2641 1857
2695 1933
2747 1989
H L
1713 924
1766 979
1824 1035
1877 1090
1935 1145
1988 1201
2045 1256
2096 1314
2156 1384
2214 1456
2264 1521
2312 1593
2358 1658
2406 1725
2452 1776
Page 67
