Part 5. Appendix
5.4. Switch box
5.4.1. HRV unit
21/01/20
|
Version 1.1
Modular L Smart
3
1
Item
Part description
1
Control PCB
2
Smart Gateway
3
Pressure differential switches
Item
Part description
PS1
Supply filter
PS2
Return filter
PS3
Supply fan
PS4
Return fan
PS5
Defrost
Figure 5-22: Smart Gateway
2
3
