Example two - fixed IP on the WAN

Company ABC likes to establish a WLAN network to support mobile communication on all employees' Notebook PCs.
MIS engineer collects information and plans the WLAN Broadband Router implementation by the following
configuration.
WAN configuration:Fixed IP
IP Address
Subnet Mask
Default Gateway
DNS Address
LAN configuration:
IP Address
Subnet Mask
Default Gateway
DHCP Client Range
WLAN configuration:
SSID
Channel Number
1. Configure the WAN interface:
Open WAN Interface Setup page, select Fixed IP then enter IP Address "192.168.2.254", subnet mask
"255.255.255.0", Default gateway "192.168.2.10".
Press
192.168.2.254
255.255.255.0
192.168.2.10
168.95.1.1
192.168.1.254
255.255.255.0
192.168.2.254
192.168.1.100 – 192.168.1.200
AP
11
button to confirm the configuration setting.
