Configuration examples

Example one - PPPoE on the WAN

Sales division of Company ABC likes to establish a WLAN network to support mobile communication on sales'
Notebook PCs. MIS engineer collects information and plans the WLAN Broadband Router implementation by the
following configuration.
WAN configuration:PPPoE
User Name
Password
Note:User Name and Password.ISP provide.
LAN configuration:
IP Address
Subnet Mask
Default Gateway
DHCP Client Range
WLAN configuration:
SSID
Channel Number
1. Configure the WAN interface:
Open WAN Interface Setup page, select PPPoE then enter the User Name "84549386" and Password "2uprlamv",
the password is encrypted to display on the screen.
Press
84549386
2uprlamv
192.168.1.254
255.255.255.0
0.0.0.0
192.168.1.100 – 192.168.1.200
AP
11
button to confirm the configuration setting.
57
