Loopcomm LP-8186C User Manual page 37

Connection Type
Idle Time
MTU Size
Attain DNS Automatically
Set DNS Manually
DNS 1
DNS 2
DNS 3
Clone MAC Address
Enable uPNP
Enable Ping Access on WAN
Enable Web Server Access on WAN
Enable IPsec pass through on VPN
connection
Enable PPTP pass through on VPN
default value is empty.
Select the connection type from pull-down
menu. There are Continuous, Connect on
Demand and Manual three types to select.
Continuous connection type means to setup
the connection through PPPoE protocol
whenever this WLAN AP Router is powered on.
Connect on Demand connection type means
to setup the connection through PPPoE
protocol whenever you send the data packets
out through the WAN interface; there are a
watchdog implemented to close the PPPoE
connection while there are no data sent out
longer than the idle time set.
Manual connection type means to setup the
connection through the PPPoE protocol by
clicking the Connect button manually, and
clicking the Disconnect button manually.
If you select the PPPoE and Connect on
Demand connection type, fill in the idle time for
auto-disconnect function. Value can be
between 1 and 1000 minutes.
Fill in the mtu size of MTU Size. The default
value is 1400.
Click to select getting DNS address for DHCP
support.
Please select Set DNS Manually if the DHCP
support is selected.
Click to select getting DNS address for DHCP
support.
Fill in the IP address of Domain Name Server
1.
Fill in the IP address of Domain Name Server
2.
Fill in the IP address of Domain Name Server
3.
Fill in the MAC address that is the MAC
address to be cloned.
Click the checkbox to enable uPNP function.
Click the checkbox to enable WAN ICMP
response.
Click the checkbox to enable web configuration
from WAN side.
Click the checkbox to enable IPSec packet
pass through.
Click the checkbox to enable PPTP packet
36
