IP Address
Subnet Mask
Gateway
Server IP Address
Server Domain Name
User Name
Password
MTU Size
Request MPPE Encryption
Attain DNS Automatically
Set DNS Manually
DNS 1
DNS 2
DNS 3
Clone MAC Address
Enable uPNP
Enable Ping Access on WAN
Enable Web Server Access on WAN
Enable IPsec pass through on VPN
connection
Enable PPTP pass through on VPN
connection
Enable L2TP pass through on VPN
If you select the PPTP support on WAN
interface, fill in the IP address for it.
If you select the PPTP support on WAN
interface, fill in the subnet mask for it.
If you select the Static PPTP support on WAN
interface, fill in the gateway for WAN interface
out going data packets.
Enter the IP address of the PPTP Server.
Assign Domain Name and dispatch to PPTP
servers. It is optional field.
If you select the PPTP support on WAN
interface, fill in the user name and password to
login the PPTP server.
If you select the PPTP support on WAN
interface, fill in the user name and password to
login the PPTP server.
Fill in the mtu size of MTU Size. The default
value is 1400.
Click the checkbox to enable request MPPE
encryption.
Click to select getting DNS address for PPTP
support.
Please select Set DNS Manually if the PPTP
support is selected.
Click to select getting DNS address for PPTP
support.
Fill in the IP address of Domain Name Server
1.
Fill in the IP address of Domain Name Server
2.
Fill in the IP address of Domain Name Server
3.
Fill in the MAC address that is the MAC
address to be cloned.
Click the checkbox to enable uPNP function.
Click the checkbox to enable WAN ICMP
response.
Click the checkbox to enable web configuration
from WAN side.
Click the checkbox to enable IPSec packet
pass through.
Click the checkbox to enable PPTP packet
pass through.
Click the checkbox to enable L2TP packet pass
