Loopcomm LP-8186C User Manual page 33

IP Address
Subnet Mask
Default Gateway
MTU Size
DNS 1
DNS 2
DNS 3
Clone MAC Address
Enable uPNP
Enable Ping Access on WAN
Enable Web Server Access on WAN
Enable IPsec pass through on VPN
connection
Enable PPTP pass through on VPN
connection
Enable L2TP pass through on VPN
connection
Apply Changes
Reset
DHCP Client
and default gateway settings need to be done.
If you select the Static IP support on WAN
interface, fill in the IP address for it.
If you select the Static IP support on WAN
interface, fill in the subnet mask for it.
If you select the Static IP support on WAN
interface, fill in the default gateway for WAN
interface out going data packets.
Fill in the mtu size of MTU Size. The default
value is 1400.
Fill in the IP address of Domain Name Server 1.
Fill in the IP address of Domain Name Server 2.
Fill in the IP address of Domain Name Server 3.
Fill in the MAC address that is the MAC
address to be cloned.
Click the checkbox to enable uPNP function.
Click the checkbox to enable WAN ICMP
response.
Click the checkbox to enable web configuration
from WAN side.
Click the checkbox to enable IPSec packet
pass through.
Click the checkbox to enable PPTP packet pass
through.
Click the checkbox to enable L2TP packet pass
through.
Click the Apply Changes button to complete
the new configuration setting.
Click the Reset button to abort change and
recover the previous configuration setting.
32
