Introduction

The WLAN AP Router is IEEE 802.11b/g WLAN AP router solution; setting SOHO and enterprise
standard for high performance, secure, manageable and reliable WLAN.
This document describes the steps required for the initial IP address assignment and other WLAN
router configuration. The description includes the implementation of the above steps.

Package contents

The package of the WLAN Broadband Router includes the following items,
The WLAN Broadband Router
The Power Adapter
The Documentation CD
RJ-45 Cable Line
One detachable antenna
Cradle

Product Specifications

Standard
Frequency Band
Radio type
Data Rate
Access Protocol
Number of operation
channel
Operation Mode
Security
RF Output Power(Typical)
Sensitivity
Antenna
Dimension (mm)
Weight
IEEE 802.11g/b
2.400GHz ~ 2.484GHz
IEEE 802.11g: OFDM(64-QAM, 16-QAM, QPSK, BPSK)
IEEE 802.11b: DSSS(CCK/DQPSK/DBPSK)
802.11g: 54, 48, 36, 24, 18, 12, 9 & 6Mbps
802.11b: 11, 5.5, 2 and 1 Mbps with auto-rate fall back
CSMA/CA
2.412~2.462GHz (Canada, FCC) / 11 Channels
2.412~2.484GHz (Japan, TELEC) / 14 Channels
2.412~2.472GHz (Euro, ETSI) / 13 Channels
AP
AP Client(ad-hoc and infrastructure)
Client
Bridge (point-to-pint and point-to-multipoint)
WDS(WirelessDescription System)
64/128bit WEP
WPA(TKIP with IEEE 802.1x)
WPA2(AES with IEEE 802.1x)
802.11g: up to 18 dBm ± 1 dBm
802.11b: up to 19 dBm ± 1 dBm
-89dBm @ 802.11g
-93dBm @ 802.11b
One detachable 2dbi antenna
146(L) x 100(W) x 24(H) (not including antenna)
245g
