Loopcomm LP-8186C User Manual page 21

Item
Disable Wireless LAN Interface
Band
Mode
Network Type
SSID
Channel Number
Data Rate
Associated Clients
Enable Mac Clone
(Single Ethernet Client)
SSID of Extended
Interface
Apply Changes
Description
Click on to disable the wireless LAN data transmission.
Click to select 2.4GHz(B) / 2.4GHz(G) / 2.4GHz(B+G)
Click to select the WLAN AP / Client / WDS / AP+WDS
wireless mode.
While Mode is selected to be Client. Click to select the
network type infrastructure or Ad hoc.
It is the wireless network name. The SSID can be 32
bytes long.
Select the wireless communication channel from
pull-down menu.
Select the transmission data rate from pull-down
menu.Data rate can be auto-select, 1M to 54Mbps or
MCS.
Click the Show Active Clients button to open Active
Wireless Client Table that shows the MAC address,
transmit-packet, receive-packet and transmission-rate
for each associated wireless client.
Take Laptop NIC MAC address as wireless client
MAC address. [Client Mode only]
Click to enable Universal Repeater Mode
Assign SSID when enables Universal Repeater Mode.
Click the Apply Changes button to complete the new
configuration setting.
20
