SERIAL INTERFACE

The EVAL-AD4111SDZ connects via the serial peripheral
interface (SPI) to the Blackfin®
board. There are four primary signals: CS , SCLK, DIN (all
inputs), and DOUT/ RDY (output from the ADC).
The EVAL-AD4111SDZ can be connected to the
ADuCM3029 EZ-KIT
evaluation board to the
user to develop their own C code rather than using the provided
evaluation software.
To operate the EVAL-AD4111SDZ in standalone mode,
disconnect any board connected to J8 and use J10 to access all
SPI signals and set the input/output voltage levels.

POWER SUPPLIES

By default, the board is powered from the
The board can be also powered from J6 and J7 (set LK3 to
Position A) or from Pin +5V on J10 (see Table 2).
The ADuM5411 isoPower® digital isolator is used to isolate
power and data lines up to 2.5 kV rms.
Table 2. Connector Details
Connector Function
J1, J2, J4 Voltage inputs to ADC
J3, J4 Current inputs to ADC
J5 Earth for electrostatic discharge (ESD)
testing
J6, J7 External supply voltage (optional)
J8 Connector to the
or EVAL-SDP-CB1Z
J10 SPI and power terminal
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
ADSP-BF527 on the SDP-B
EVAL-
in the same way. Connecting the
EVAL-ADuCM3029 EZ-KIT
SDP-B connector.
EVAL-ADuCM3029 EZ-KIT

ANALOG INPUTS

There are two types of analog inputs: voltage and current.
Eight voltage inputs are available on J1 and J2. Four current
inputs are available on J3.
If a different common voltage must be set for single-ended
measurement, remove LK2 and connect the desired voltage to
VCOM on J1.
allows the

REFERENCE OPTIONS

The EVAL-AD4111SDZ includes an external 2.5 V reference,
the ADR4525ARZ. By default, LK1 is inserted, connecting the
external reference to the REF+ pin of the AD4111.
Remove LK1 if using a different single-ended external reference.
In the evaluation software, click the blue pop-up button
associated with Setup 0 to Setup 7 to select the reference used
for conversions by the AD4111. The pop-up button is located
below the external reference controls in the block diagram
(Label 9 in Figure 16).
Connector Type
Connector, header, 90°, 5-position, 3.81 mm
Connector, header, 90°, 5-position, 3.81 mm
1.25-MS3 ring tongue terminal, M3, No. 5,
16 AWG, 1.65 mm²
Connector, header, 90°, 5-position, 3.81 mm
120-way connector, 0.6 mm pitch
Header, in line, 7-position, 100 mil
Rev. A | Page 6 of 26
EVAL-AD4111SDZ User Guide
Manufacturer Part Number
Phoenix Contact MC 1, 5/5-G-3, 81
Phoenix Contact MC 1, 5/5-G-3, 81
Japan Solderless 1.25-MS3
Terminals
Phoenix Contact MC1.5/3-G-3.81
Hirose FX8-120S-SV (21)
Wurth Elektronik 61300711121
