Analog Devices EVAL-AD4111SDZ User Manual page 18

UG-1124
J4-9
J3-4
J4-8
J3-3
J4-7
J3-2
J4-6
J3-1
J4-10
J3-5
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
CURRENT INPUTS
F1
2R8 - 50R
MF-USMF005-2
50 mA
F2
2R8 - 50R
MF-USMF005-2
50 mA
F3
2R8 - 50R
MF-USMF005-2
50 mA
F4
2R8 - 50R
MF-USMF005-2
50 mA
10V, 400W
SMAJ10CA
Figure 23. Current Input Front End Schematic
Rev. A | Page 18 of 26
EVAL-AD4111SDZ
R25
180R
R26
180R
R27
180R
R28
180R
D10
GND_ISO
User Guide
IIN0
C33
470pF
GND_ISO
IIN1
C34
470pF
GND_ISO
IIN2
C35
470pF
GND_ISO
IIN3
C36
470pF
GND_ISO
