EVAL-AD4111SDZ
Setting Up the System for Data Capture
After completing the steps in the Software Installation Procedures
section and the Evaluation Board Hardware section, set up the
system for data capture as follows:
1. Allow the Found New Hardware Wizard to run after
connecting the
the user may need to search for the SDP drivers. Choose to
automatically search for the drivers for the
prompted by the operating system.
2. Check that the board is connecting to the PC correctly
using the Device Manager of the PC. Access the Device
Manager as follows:
a. Right-click My Computer and then click Manage.
b. A dialog box appears asking for permission to allow
the program to make changes to the PC. Click Yes.
c. The Computer Management box appears. Click
Device Manager from the list of System Tools
(see Figure 12).
d. The SDP-B
Tools, which indicates that the driver software has
been installed, and that the board is connected to the
PC correctly.
Figure 12. Device Manager: Checking if the Board is Connected
Launching the Software
After completing the steps in the Setting Up the System for Data
Capture section, launch the AD411x Eval+ software as follows:
1. From the Start menu, click Programs > Analog Devices >
AD411x Eval+ > AD411x Eval+. The dialog box in
Figure 13 appears. Select AD4111 Evaluation Board, and
the main window of the software appears as shown in
Figure 16.
Figure 13.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
User Guide
SDP-B board to the PC. For Windows® XP,
SDP-B
board appears under ADI Development
to the PC Correctly
AD4111 Evaluation Board Selection
2. If the EVAL-AD4111SDZ evaluation system is not
connected to the USB port via the
software is launched, the software displays the dialog box
shown in Figure 14. Connect the evaluation board to
the USB port of the PC, wait a few seconds, click Refresh,
and the option shown in Figure 13 appears.
board if
Figure 14. Evaluation Board Selection: No Board Connected
3. If Step 1 was completed correctly, the dialog box shown in
Figure 15 appears. Quickstart mode provides a simplified
version of the software that can be used as a starting point
for evaluating the AD4111. This mode provides a graphical
user interface (GUI) for setting up inputs, as shown in
Figure 16, and allows the user to further configure the
device using the blue configuration buttons (Label 8 in
Figure 16).
Advanced mode can be used when more configurability of
the inputs is required. In this mode, the input GUI is not
available. However, the user has access to the Register tab,
which provides full control of the
When operating in advanced mode, the user must consult
with and have a good understanding of the
sheet.
Rev. A | Page 9 of 26
SDP-B
Figure 15. AD411x Eval+ Startup Mode Selection
AD4111
UG-1124
when the
register map.
AD4111 data
