Device Error
The Device Error indicator (Label 22 in Figure 18) illuminates
in the waveform tabs when a cyclic redundancy check (CRC)
error or an error in the ADC is detected. More specific
information of the error can be found by clicking Summary in
the Configuration tab (Label 12 in Figure 16).
Analysis Input
The Noise Analysis box shows the analysis of the input selected
via the analysis control (Label 23 in Figure 18).
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
User Guide
Noise Analysis
The Noise Analysis section (Label 24 in Figure 18) displays the
results of the noise analysis for the selected analysis input,
including both noise and resolution measurements.
Input Range
Range (Label 25 in Figure 18) is an indicator in quickstart
mode. The value is selected per the inputs on the
Configuration tab (Label 1 in Figure 16). In advanced mode,
Range is a control that allows the user to select an input range
for the input chosen for Noise Analysis (Label 23 in Figure 18).
