Specifications - Phenix Technologies HC-75C Operator's Manual

Input: 480 VAC, 60 Hz, 400 AAC
(Note: The above current levels are based on the 30 minute duty cycle. To estimate the current draw on
the facility power at different duty cycles, multiply the above currents by the ratio of the output currents.
Ex.: An HC-75C will draw approximately 7.5 times the above current at the 1 second duty cycle.)
Output:
DUTY CYCLE
HC-12C
HC-20C
HC-40C
HC-75C
*Note: The HC-C Controller will impose a shutdown and a 5-minute off time if one of the above limits is exceeded.
DUTY CYCLE
HC-12C
HC-20C
HC-40C
HC-75C
*Note: The HC-C Controller will impose a shutdown and a 5-minute off time if one of the above limits is exceeded.
Connection /
Series / 60Hz
Frequency
HC-12C
HC-20C
HC-40C
HC-75C
HC 75C
SECTION 2: SPECIFICATIONS
OUTPUT CURRENT SPECIFICATIONS
(PARALLEL CONNECTION)
1 Second ON / 1 Minute ON /
2 Minutes OFF 10 Minutes OFF
12,000 A
20,000 A
40,000 A
75,000 A
OUTPUT CURRENT SPECIFICATIONS
(SERIES CONNECTION)
1 Second ON / 1 Minute ON /
2 Minutes OFF 10 Minutes OFF
6,000 A
10,000 A
20,000 A
37,500 A
OUTPUT VOLTAGE SPECIFICATIONS
(OPEN CIRCUIT)
Parallel / 60Hz
15 V 7.5 V
20 V 10 V
24 V 12 V
32 V 16 V
30 Minute ON /
30 Minutes OFF
2,500 A 1,700 A
4,500 A 3,000 A
9,000 A 6,000 A
15,000 A 10,000 A
30 Minute ON /
30 Minutes OFF
1,250 A 850 A
2,250 A 1,500 A
4,500 A 3,000 A
7,500 A 5,000 A
Series / 50Hz
12.5 V
16.6V
20 V
26.6 V
Continuous
1,200 A
2,000 A
4,000 A
7,500 A
Continuous
600 A
1,000 A
2,000 A
3,750 A
Number of
Parallel / 50Hz
Taps
6.25 V
8.3 V
10 V
13.3 V
2-1
3
4
6
8
