Phenix Technologies HC-75C Operator's Manual page 41

Qty Phenix Part #
1 38602282
2 1356214
2 1356215
1 1092590
1 1099120
1 1600609
1 1600751
1 30030007
1 1152903
1 1152906
2 1152902
2 1152910
1 1506560
10 1780025
2 1603667
2 1603921
1 1603610
1 1603920
1 1603605
1 1603910
5 2350125
4 1705087
6 1705094
8 1701361
1 30180002
1 1423265
6 1606150
1 1606140
1 1606100
1 31115600
1 31115520
1 31125210
1 1590295
2 1714010
1 1740201
1 1761055
1 1355315
1 1769998
1 1740300
1 1763000
1 1159922
1 1808210
1 1565225
1 1863360
HC 75C
HC-75C (600V) PARTS LIST
Item
REGULATOR AND HIGH CURRENT SECTION
T301
BP201,3
BP202,4
C201
C202
CB201
CB202
CBL201/CON101
CON201
CON201
CON202, CON203
CON202, CON203
CT201
D201-D210
F201, F202
F201, F202
F203
F203
F204
F204
FAN201- FAN205
K201- K204
K205- K210
K211-214
KS201-204
Leads-Continuity
LMP201
MOV201-6
MOV207
MOV208
PCB201
PCB202
PCB203
PS201
R201, R202
R203
R204
R205
R205
R206
R207
RCP101
SCR201, SCR202
SCRC201
SW201
Description
TRANSFORMER, HIGH CURRENT
BINDING POST, BLACK
BINDING POST, RED
CAPACITOR
CAPACITOR
CIRCUIT BREAKER
CIRCUIT BREAKER
RIBBON CABLE ASSEMBLY
RECEPTACLE, FEMALE, GREEN
PLUG, GREEN
RECEPTACLE
PLUG
COIL FOR CURRENT METER
DIODE
FUSE
FUSE HOLDER, 600V, 2 POLE
FUSE, FAST ACTING
FUSE HOLDER, 3AG PANEL MOUNT
FUSE, FAST ACTING
FUSE HOLDER, 3AG, SINGLE
FAN AND MOTOR
CONTACTOR, 24VDC COIL
CONTACTOR, 24VDC COIL
RELAY
HC CONTINUITY LEAD SET
LAMP, NEON, 125V
MOVISTOR
MOVISTOR
MOVISTOR
TRIGGER BOARD, PCB1156
INPUT/OUTPUT BOARD, PCB1155B
RMS TO DC, PCB1252
POWER SUPPLY, 24VDC
RESISTOR
RESISTOR
POTENTIOMETER
KNOB, 1" DIA.
POTENTIOMETER
RESISTOR
THERMISTOR
OUTLET, DUPLEX 120V, 15A
SCR ASSY
SCR CONTROLLER
SWITCH
15-2
