SECTION 13: ELECTRICAL SCHEMATICS
HC Controller
Drawing Number
1.
9304593
2.
31138900
3.
31139100
HC Regulator / Transformer Cabinet(s)
Drawing Number
1.
9304592
2.
31115520
3.
31115600
4.
31125210
HC 75C
Description
HC-C Controller Electrical Schematic
PCB 1389, HC Interface BD
PCB1391, HC Interconnect BD
Description
HC-75C Electrical Schematic
PCB 1155B, HC I/O Interface Schematic
PCB 1156, SCR Trigger Board
PCB 1252A, RMS-to-DC Converter
13-1
