Set ' R S232
RS232', press 'RESET/ENTER
Step 12
Press 'MAX/ESC
MAX/ESC' twice to return to the measurement screen.
Please Note: If using the stand in conjunction with VectorPro, please ensure that the units selected
Please Note:
on the gauge match the unit selected within the software.
5.7
Connect the Test Stand to a PC (VectorPro Users Only)
If you are using VectorPro software, connect the USB B port, located on the test stand, to a PC using an
appropriate cable (part no. 351-093
part no. 351-093).
Important! Please install VectorPro software on the assigned PC before
Important!
connecting the test stand to that computer. Once the software is installed
and the stand is connected, the stand will show as connected. This is shown
in the image to the right.
5.8

Cable Management

It is essential that no cables interfere with the controls or any moving parts. Failure to do so could lead to injury or
damage to the equipment.
5.9

Attaching Grips and Fixtures

The most commonly-used upper fixture used is the 100 mm upper fixing plate with a diameter capacity of 10 mm
to 78 mm. This is fixed to the adaptor on the torque transducer using a 2.5 mm Hex key to secure the four
countersunk screws supplied.
The fixture can also be quickly removed using the two grub screws in the adapter, accessed through
slots in the sides of the fixing plate, as shown below.
RESET/ENTER' to continue.
19
