Configure I/O Interface

Power up the keypad. Access Configuration Menu. LCD displays:
Press until the LCD displays:
Press . LCD displays:
Press to confirm. LCD displays:
Enter Master code. LCD displays:
Enter an ID RS485 and press

Remove I/O Interface

Power up the keypad. Access Configuration Menu. LCD displays:
Press until the LCD displays:
Press to confirm. LCD displays:
Enter Master code. LCD displays:

Display contrast

Power up the keypad. Access Configuration Menu. LCD displays:
Press until the LCD displays:
Press . LCD displays:
Enter a contrast level (between 1 and 9) and press
LCD displays:
If Dynamic codes have been activated, along with the deletion of all static codes
(including the Master code), it is possible to access the Display contrast menu by
pressing and holding
For further information, see the paragraph Dynamic codes activation with static codes
deleting, page 18.
IU_TechMaster_05_eng
to confirm. LCD displays:
.
User instructions
CONFIGURE I/O
RS485 ID 01
MASTER CODE
X X X X X X X X
REMOVEE I/O
MASTER CODE
X X X X X X X X
to confirm.
INSTALL
LOCKS
INTERFACE
RS485 ID XX
OPERATION
DONE
INSTALL
LOCKS
INTERFACE
OPERATION
DONE
INSTALL
LOCKS
DISPLAY
CONTRAST
ADJUST
CONTRAST
X
OPERATION
DONE
25 of 28
