Page 2
Choose your configuration Last option forces the Manager to access users management, audit and time delay functions in dual RTC recovery (Master mode and Manager) RTC auto calibration If pin option is not selected the keypad must have dallas Always: keypad can reader.
Page 3
Set lock users Installed – deleted – blocked Code Code + dallas key Time lock Set time lock Weekly time lock: 4 periods each day Closing periods: 30 events (max 14 days) Opening periods: 30 events (max 14 days)
Page 4
Write a setup key Open MiniTech setup PC software Connect the USB interface to the dallas reader and to the PC Connect dallas key to the reader Press “Write setup key” Write a reset key Open MiniTech setup PC software Connect the USB interface to the dallas reader and to the PC Connect dallas key to the reader...
Page 5
Set your MiniTech Connect MiniTech lock to the keypad Write a setup key Connect the setup key to the dallas reader Switch on the keypad, press and hold 2 Connect the reader to the keypad jack connector Check time and date Wait for the upload to be completed Tools you need…...
Page 6
Wrong configuration? Reset your lock… Connect keypad and lock Connect the reset box to the BAT connector of the lock Write a reset key Connect the reset key to the dallas reader Switch on the keypad, press and hold 2 Connect the reader to the jack connector of MiniTech keypad The system will be reset in few seconds –...
Page 7
Set your audit key Open MiniTech audit PC software Connect the USB interface to the dallas reader and to the PC Connect dallas key to the reader Press “Create audit key” Tools you need… MiniTech audit software USB interface N42180/T Dallas reader N42170/D Dallas key N1996...
Page 8
Audit your MiniTech Connect the audit key to the dallas reader Access audit function Connect the reader to the keypad jack connector Wait for the download to be completed Tools you need… Dallas reader N42170/J Setup dallas key N1996...
Page 9
Read your audit Open MiniTech audit PC software Connect the USB interface to the dallas reader and to the PC Connect the audit key to the reader Press “Read audit key” Wait for the upload to be completed Filter, save or export events to pdf Tools you need…...
