Tecnosicurezza TechMaster User Instructions

TechMaster
User instructions
Dallas key
In the event that the user is composed of "code + Dallas key", before or after entering the code, the Dallas key must be
placed on the appropriate Dallas key reader.
Override users
Override users open without waiting the time delay. In the default programming they are set in dual code opening but,
upon request, the single opening mode can also be set.
Silent alarm
It is activated by increasing or decreasing the last digit by one number when entering the opening code.
Penalty
After four attempts to enter an incorrect code, the lock starts a 4-minute delay period. Each attempt to enter the code
within the 4 minutes delay period restarts the count.
Low battery warning
A message on the display and a long beep during opening indicates a low battery level. Replace immediately the low battery
with a new Alkaline battery.
Sound signals
A double beep normally indicates a correct operation. A long beep
of the operation itself.
Reccomendations
Do not use easily identifiable codes such as 123456, dates of birth or other personal information.
Opening
(It is recommended to change the factory code before use and to safely store the new code)
Press any key to turn on the device. The display shows the message:
Press to open with Manager code or go to the next step.
Enter the opening code. The display shows the time delay counting if programmed.
At the end of the time delay, the display shows the counting of the open window.
Enter the opening code. The display shows the message:
Open the safe door within 4 seconds.
Dual code opening
(It is recommended to change the factory code before use and to safely store the new code)
Press any key to turn on the device. The display shows the message:
Press to open with Manager code or go to the next step.
Enter the opening code. The display shows the time delay counting if programmed.
At the end of the time delay, the display shows the counting of the open window.
Enter the 1° opening code. The display shows the message:
Enter the 2° opening code. The display shows the message:
Open the safe door within 4 seconds.
Default codes
Master 1 2 3 4 5 6 7 8
Manager 0 1 - 1 2 3 4 5 6 + Optional Dallas key
User 2 0 2 - 0 2 0 2 0 2 + Optional Dallas key
User 3 0 3 - 0 3 0 3 0 3 + Optional Dallas key
User x x x – x x x x x x + Optional Dallas key
IU_TechMaster_easy_03_eng
indicates an incorrect operation and the end
USER CODE
X X – X X X X X X
MANAGER
X X X X X X
TIME DELAY
00:59
OPEN WINDOW
00:01
OPEN
USER CODE
X X – X X X X X X
MANAGER
X X X X X X
TIME DELAY
00:59
OPEN WINDOW
00:01
2° USER CODE
X X – X X X X X X
OPEN WINDOW
