  • Page 1 Pulse Pro User Instructions...

  • Page 2: Company

    Founded in 1983 with the aim of providing a complete range of professional products, Tecnosicurezza is now a consolidated reality in the field of locks and security systems for safes. The experience gained in over 35 years of activity in the security sector has allowed the designing and manufacturing of high technology and reliability systems, which continue to receive the approval of an increasingly demanding clientele.

  • Page 3: Table Of Contents

    User instructions Pulse PRO Table of contents COMPANY TABLE OF CONTENTS IMPORTANT NOTES! GENERAL INFORMATION OVERVIEW FUNCTIONS LOCK OPENING SETUP MODE ANAGER AND STANDARD USERS VERRIDE USERS CODE CHANGING (FUNCTION 0) INSTALL/DISABLE/DELETE USERS ISABLE NABLE USERS FUNCTION ELETE USERS FUNCTION...
  • Page 4 User instructions Pulse PRO EMERGENCY RESCUE CODE (ERC) RESET MODE (WITH RESET BOX) CONFIGURATION NUMBER CONTACTS 4 di 26 IU_PulsePro_08...

  • Page 5: Important Notes

    User instructions Pulse PRO Important notes • Before installing this product, please read carefully the installation and operating instructions. • Locks have been designed to correctly operate in a temperature range from -5°C to + 50°C and and in an environment with non-condensing humidity between 25% and 90%.

  • Page 6: General Information

    User instructions Pulse PRO General information Using your keypad The keypad automatically switches OFF if no buttons are pressed within 5s. Press to cancel an operation. A short beep is produced. To start a time delay counting (if set), enter an opening combination: LED flashes every 2s, indicating the counting.
  • Page 7 User instructions Pulse PRO To open or access the menu in dual mode (if set), enter the first user's combination: the led flashes fastly. Then, enter the second user's combination. To stop a dual mode opening, press after having introduced the first user’s combination and while the led is flashing.
  • Page 8 Manager management. The PC is not necessary! Pulse PRO can be also used with analog locks such as EM2020, EM2050, EM3520, EM3520/S, EM3550, EM3550/S and EM6050. If the keypad is connected with one of these locks, the options enabled are only the ones corresponding to the locks properties, hence please refer to the relative user manuals.

  • Page 9: Overview Functions

    ERC code (Emergency Rescue Code) is always built as ID + 8 digits. ERC, random code provided by Tecnosicurezza: 98-98989898. ERC, random code provided by Tecnosicurezza: 99-99999999. This user manual describes the standard programming. According such programming and unless different requests while ordering the product, an opening can be performed by entering single users codes (no dual mode) and without time delay.

  • Page 10: Lock Opening

    Lock can be powered with: • an ALKALINE 9V battery located in the battery compartement below the keypad; • an internal battery box provided by Tecnosicurezza (6 ALKALINE 1.5 batteries); • A power adapter (ref. N1212) with power supply interface (ref. T6005/W or T6005) both provided by Tecnosicurezza.

  • Page 11: Override Users

    User instructions Pulse PRO Enter a combination during the opening window (2 combinations in case of dual mode opening). 2 short beeps are produced and the lock can be opened. Override users Enter an opening combination. 2 short beeps are produced and the lock can be opened.

  • Page 12: Disable/Enable Users (Function 2)

    User instructions Pulse PRO Enter the Manager combination. 2 short beeps are produced. Enter the new user ID. 2 short beeps are produced. Enter the code (and/or the Dallas key) of the new user. 2 short beeps are produced. Enter again the code (and/or the Dallas key) of the new user for confirmation.

  • Page 13: Lock Setup (Function 6)

    User instructions Pulse PRO Enter the following sequence of buttons: Any working button produces 2 short beeps. A damaged button produces a long beep and the keypad switches OFF. Lock setup (function 6) This function is used to set up the options below.

  • Page 14: Door Alarm

    User instructions Pulse PRO Door alarm With door alarm enabled, if the bolt remains open for more than the time set, the keypad produces a series of multiple beeps. Enter Default setting: “Door alam” When door alarm is disabled, a single beep (bad sound) is produced. 2 disabled short beeps are instead produced when door alarm is enabled.

  • Page 15: Expiring Codes

    User instructions Pulse PRO setting the date itself. Enter A single beep (bad sound) is produced for EU format DD/MM/YY and 2 beeps instead for US format MM/DD/YY. Enter “0” for EU format or “1” for US format. 2 beeps are produced.

  • Page 16: Audit

    Before performing this download, it is necessary to connect the keypad and the lock with the PC using an USB interface provided by Tecnosicurezza. Run the software Pulse Pro Audit, use the “Download” session to select the number of 16 di 26...

  • Page 17: Configuration Selection (Function 8)

    For further information regarding the users provided by each configuration, use the software PulsePro Setup and refer also to the user manual IU_PulsePRO_setup_XX or contact Tecnosicurezza. Press and hold until 2 short beeps are produced. If the lock is in pre-setup mode, skip the next 2 steps.

  • Page 18: Time Delay (Function 9)

    User instructions Pulse PRO Enter again the configuration number for confirmation. 2 short beeps are produced. Enter the date format (0=EU format, 1=US format). The led flashes. If the operation is successful, 2 short beeps are produced and the led switches OFF.

  • Page 19: Date Setting

    OFF. Emergency Rescue Code (ERC) The Emergency Rescue Code code can be programmed by Tecnosicurezza upon specific request. It allows to perform the emergency rescue operation. This operation is useful when all the codes are lost and when there is no possibility to open the lock. All the other settings are kept.
  • Page 20 Manager and user 01. Every time the Manager performs an opening, user 01 code is restored to its default value (01-010101). The only custom configurations that can be set through the software Pulse PRO Setup are those ones in between 90 and 98. Please refer to the user manual IU_PulsePRO_setup_XX for further information or contact Tecnosicurezza.
  • Page 21 User instructions Pulse PRO 10 USERS Manager Configuration Manager Configuration management Manager Master number management Manager Master number 10 Users 10 Users in dual mode ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓...
  • Page 22 User instructions Pulse PRO 10 USERS + 1 OVERRIDE USER, Dual mode Manager Configuration Manager Configuration Manager Master Manager Master management number management number 10 Users + 1 Override user in dual mode 10 Users + 1 Override user in dual...
  • Page 23 User instructions Pulse PRO 50 USERS Manager Configuration Manager Configuration management Manager Master number management Manager Master number 50 Users 50 Users in dual mode ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓...
  • Page 24 User instructions Pulse PRO 50 USERS + 10 OVERRIDE USERS, Dual mode Manager Configuration Manager Configuration management Manager Master number management Manager Master number 50 Users + 10 Override users in dual mode 50 Users + 10 Override users. All the...
  • Page 25 Istruzioni utente Pulse PRO NOTES 25 di 26 IU_PulsePro_08...
  • Page 26 Contacts GLOBAL HEADQUARTERS USA HEADQUARTERS SPAIN HEADQUARTERS Tecnosicurezza SpA Tecnosicurezza Inc. Tecnosicurezza Sa Via Cesare Battisti, 276 50, Thomas Lane C/Menor, 4 - Nave 10 37057 San Giovanni Lupatoto Pol.
