Rotary Chuck - K11-160 Iso 702-2 - Optimum OPTI turn TU 3008G Operating Manual

4.25

Rotary chuck - K11-160 ISO 702-2

Material of the chuck body
Camlock direct fixing (without flange)
Maximum clamping diameter [ mm ]
Lathe chuck passage [mm]
max. static clamping force ∑
Maximum torque with lathe chuck key [ Nm ]
Lathe chuck weight [ kg ]
Weight of a jaw [ kg ]
with internal grading
Mass of chuck jaw set [ kg ]
Centrifugal moment M
with internal grading
Gravity distance r
Version 1.1.6 - 2021-09-17
Type
max. speed [ rpm ]
[ kN ]
S
for one jaw [ kgm ]
c
of jaw [ mm ]
o
D
D1
D2
D3
D4
H
1
h
h
1
Translation of original instruction
H1
h
h1
K11-160/D4
( 3442761 )
Cast steel
DIN ISO 702-2 Size no. 4
0.0164
63.513
160
40
3000
24
160
10
0.318
0.954
40.62
160
82.6
50
117
71
13
10
3442761 GB
59
