Tailstock
Tool holder
Attachment screw lathe saddle
4.2.2

Overview of indicator elements

1
2
Scale cross offset tailstock
( 1 ) Oil sight glass speed gear unit
( 2 ) Oil sight glass feed gear
Operation
TU3008G
GB
Version 1.1.6 - 2021-9-17
Translation of original instruction
27
