Hand Crimp Tool for FIQD Terminals
ServiceGrade™ ™ ™ ™
Hand Crimp Tool

FEATURES

A full cycle ratcheting hand tool ensures complete crimps
Ergonomic soft grip handles for comfortable crimping
For crimps conforming to industry standards such as UL requirements, use the 64001-4500
Premium Grade™ hand tool

SCOPE

Products: Fully insulated Quick Disconnect for 14-22 AWG and .Step Down Butt Splices for 10-12 to 14-16
AWG and 14-16 to 18-22 AWG.

Crimping Information:

Crimp the terminal and appropriate gauge wire in the specified profile.
Note:
An occasional, destructive, pull force test with the terminal and wire crimped should be performed to check hand tool
crimp. The pull force value must exceed the terminal's minimum pull force specifications listed above. If values do
not exceed the minimum pull force when all instructions are followed then a new tool is required.
Doc No: ATS-640160042
Revision: A
Application Tooling
Specification Sheet
Wire Size
Description
AWG mm
10
5.00
12
3.30
14
2.00
Quick
16
1.30
Disconnects
18
0.80
20
0.50
22
0.35
10
5.00
12
3.30
14
2.00
Splices
(Butt splices or
16
1.30
parallel splices)
18
0.80
20
0.50
22
0.35
▼
Pull force test samples should not have the wire insulation crimped.
Release Date: 07-13-12
Revision Date: 07-13-12
Pull Force UL486A
Tool Crimp Profile
Minimum
▼
N
Lb.
22-18 16-14 12-10
2
356.0
80.0
311.5
70.0
222.6
50.0
133.5
30.0
89.0
20.0
X
57.9
13.0
X
35.6
8.0
X
178.0
40.00
155.7
35.00
111.2
25.00
66.8
15.00
44.5
10.00
X
44.5
10.00
X
35.6
8.0
X
UNCONTROLLED COPY
Order No. 64016-0042
Markings
X
X
X
X
X
X
X
X
Page 1 of 4
