Tool Kit for Quick Disconnect Flag Female Terminal
Tool Kit
Order No. 63819-7870
FEATURES
A full cycle ratcheting hand tool ensures complete crimps
%
Ergonomically designed soft handles
%
Precisely designed crimping profiles with simple contact positioning
%
Easy handling due to outstanding force ratio
%
Tool kits are easily installed into the Hand Crimp Tool or the 63816-0300 Power Crimp Head which is installed
into the 63816-0200 (110 V) or the 63816-0250 (220 V) Battery Powered Tool.
Many different Tool kits can be used with a single Battery Powered Tool.
This tool is IPC/WHMA-A-620 Class 2 and RoHS compliant.
SCOPE
Products: Quick Disconnect Flag Female Terminal 4.8 by 0.8 Tabs 18-20 AWG (.50-.80mm
Terminal Order No.
Terminal
Series No.
Available in Reel form only
94536-0100
94536
94536-0101
The terminals above are reeled parts only. Customer to cut off terminal from reel: 0.51 mm (.020") maximum.
To achieve optimum IPC-A620 insulation crimps, use this insulation OD range.
Overall insulation OD specification for terminal.
DEFINITION OF TERMS
ROLLING
Doc No: ATS-6381978HM Release Date: 07-30-09
Revision: B
Application Tooling
Specification Sheet
Wire Size
AWG mm²
18-
N/A 2.70-3.40 .106-.133
94536-1100
94536-1101
20
N/A 2.00-2.90 .079-.114
STRIP LENGTH
WIRE
INSULATION
CRIMP
BEND UP
TWISTING
BEND DOWN
Revision Date: 09-20-10
Insulation Diameter
IPC/WHMA-A620
Terminal
mm
In.
mm
3.50
CUT-OFF TAB
CONDUCTOR
CRIMP
CRIMP HEIGHT
UNCONTROLLED COPY
TYPE 4C
Hand Crimp Tool
Order No. 63819-7800
2
).
Strip Length
Maximum
In.
mm
In.
.138
4.40-5.40 .173-.213
Page 1 of 8
