Proline Promass I 100

Operable flow range

Output signal

Endress+Hauser
Maximum possible full scale value:
 =  · ρ : x = 70 000 kg/h · 60.3 kg/m³ : 90 kg/m³ = 46 900 kg/h
max(G) max(F) G
Recommended measuring range
"Flow limit" section (→  48)
Over 1000 : 1.
Flow rates above the preset full scale value are not overridden by the electronics unit, with the result
that the totalizer values are registered correctly.

Output

Current output
Current output
Maximum output values
Load
Resolution
Damping
Assignable measured
variables
Pulse/frequency/switch output
Function
Version
Maximum input values
Voltage drop
Pulse output
Pulse width
Maximum pulse rate
Pulse value
Assignable measured
variables
Frequency output
Output frequency
Damping
Pulse/pause ratio
4-20 mA HART (active)
• DC 24 V (no flow)
• 22.5 mA
0 to 700 Ω
0.38 µA
Adjustable: 0.07 to 999 s
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
The range of options increases if the measuring device has one or more
application packages.
Can be set to pulse, frequency or switch output
Passive, open collector
• DC 30 V
• 25 mA
For 25 mA: ≤ DC 2 V
Adjustable: 0.05 to 2 000 ms
10 000 Impulse/s
Adjustable
• Mass flow
• Volume flow
• Corrected volume flow
Adjustable: 0 to 10 000 Hz
Adjustable: 0 to 999 s
1:1
