Ex connection data
12
Operating tool
• Via digital communication:
– HART protocol
– PROFIBUS DP
– Modbus RS485
– EtherNet/IP
• Via service interface
Plain text display With information on cause and remedial measures
Additional information on remote operation (→  74)
Web browser
Plain text display With information on cause and remedial measures
Light emitting diodes (LED)
Status information
These values only apply for the following device version:
Order code for "Output", option M: Modbus RS485, for use in intrinsically safe areas
Safety Barrier Promass 100
Safety-related values
Supply voltage
2 (L-)
U = DC 24 V
nom
U = AC 260 V
max
Intrinsically safe values
Supply voltage
20 (L-)
For IIC
For IIB
* The gas group depends on the sensor and nominal diameter.
For an overview and for information on the interdependencies between the gas group - sensor - nominal
diameter, see the "Safety Instructions" (XA) document for the measuring device
Status indicated by various light emitting diodes
The following information is displayed depending on the device version:
• Supply voltage active
• Data transmission active
• Device alarm/error has occurred
• EtherNet/IP network available
• EtherNet/IP connection established
Terminal numbers
1 (L+)
Terminal numbers
10 (L+)
U = 16.24 V
o
I = 623 mA
o
P = 2.45 W
o
*
: L = 92.8 µH, C = 0.433 F, L
o o
*
: L = 372 µH, C = 2.57 F, L
o o
Proline Promass I 100
Signal transmission
26 (A) 27 (B)
U = DC 5 V
nom
U = AC 260 V
max
Signal transmission
62 (A) 72 (B)
/R = 14.6 H/Ω
o o
/R = 58.3 H/Ω
o o
