Proline Promass I 100
Endress+Hauser
Order code for "Housing", option A "Compact, coated aluminum"
The various cable entries are suitable for hazardous and non-hazardous areas.
Cable entry/cable gland
Cable gland M20 × 1.5
Adapter for cable entry with internal thread G ½"
Adapter for cable entry with internal thread NPT ½"
Order code for "Housing", option B "Compact, hygienic, stainless"
The various cable entries are suitable for hazardous and non-hazardous areas.
Cable entry/cable gland
Cable gland M20 × 1.5
Adapter for cable entry with internal thread G ½"
Adapter for cable entry with internal thread NPT ½"
Device plug
Electrical connection
Plug M12x1
Sensor housing
• Acid and alkali-resistant outer surface
• Stainless steel 1.4301 (304)
Measuring tubes
Grade 9 titanium
Surface quality:
• Not polished
• Ra = 0.8 µm (32 µin)
max
• Ra = 0.4 µm (16 µin)
max
Process connections
• Flanges according to EN 1092-1 (DIN 2501) / according to ASME B16.5/ according to JIS:
– Stainless steel 1.4301 (304)
– Wetted parts: Grade 2 titanium
• All other process connections:
Grade 2 titanium
List of all available process connections (→  74)
Seals
Welded process connections without internal seals
Safety Barrier Promass 100
Housing: Polyamide
Material
Nickel-plated brass
Material
Stainless steel, 1.4404 (316L)
Material
• Socket: Stainless steel, 1.4404 (316L)
• Contact housing: Polyamide
• Contacts: Gold-plated brass
