Proline Promass I 100
Endress+Hauser
1", 1½", 2" -Tri-Clamp for pipe size: titanium (order code for "Process connection", option FTW)
DN Clamp
[mm]
80
3A version available (order code for "Additional approval", option LP) in combination with Ra ≤ 0.8 µm, Ra ≤
0.4 µm (order code for "Measuring tube material", option CB, CD)
FB = Full bore
1) Order code for "Process connection", option FRW
¾" Tri-Clamp: titanium (order code for "Process connection", option FEW)
DN Clamp
[mm]
8
15
15 FB
3A version available (order code for "Additional approval", option LP) in combination with Ra ≤ 0.8 µm, Ra ≤
0.4 µm (order code for "Measuring tube material", option CB, CD)
FB = Full bore
½" Tri-Clamp: titanium (order code for "Process connection", option FBW)
DN Clamp
[mm]
8
15
3A version available (order code for "Additional approval", option LP) in combination with Ra ≤ 0.8 µm, Ra ≤
0.4 µm (order code for "Measuring tube material", option CB, CD)
Eccentric Tri-Clamp
34 Engineering unit mm (in)
Eccentric Tri-Clamp: Titanium
DN Order code for
[mm] "Process connection",
Option
8 FEA
15 FEC
A
[in] [mm]
3 90.9
A
[in] [mm]
¾ 25.0
¾ 25.0
¾ 25.0
A
[in] [mm]
½ 25.0
½ 25.0
Clamp
[in]
½
¾
B
[mm]
72.9
B
[mm]
16.0
16.0
16.0
B
[mm]
9.5
9.5
+1,5 (+0.06)
L
-2,0 (-0.08)
A B
[mm] [mm]
25 9.5
25 15.75
L
[mm]
1 268
L
[mm]
426
462
602
L
[mm]
426
462
A0015625
L
[mm]
427
463
