Design and function
Welding torch holder
5.4
Welding torch holder
The item described in the following is part of the machine´s scope of delivery.
Item Symbol
1
2
3
4
•
Use the mounting screws to screw the torch holder onto the crossmember of the transport handle.
•
Insert the welding torch into the welding torch holder as shown.
52
Description
0
Crossmember of the transport handle
Torch holder
Fixing screws (x 4)
Fan-type lock washers
Figure 5-29
099-000237-EW501
25.04.2019
