Machine description – quick overview
Description
0
Lid > see 4.3.1 chapter
Push-button for switching the wire feed speed display
m/min
Wire feed speed in meters per minute.
ipm
Wire feed speed in inch per minute.
Display, left
Wire feed speed
Rotary dial, welding parameter setting
To set the wire feed speed and other welding parameters.
Operating mode selection push-button
Non-latched, manual
Latched, manual
Non-latched, automatic
Latched, automatic
Signal light lights up in red: TIG tack welding
Rotary knob to set the parameters for program number
•
Selection of the program number
Display switching push-button
Prog
Program number display
Display, right
Program number
Machine control – Operating elements
21
