Permitted torch coolant

Coolant
KF 23E (Standard)
KF 37E
5.1.8.2

Maximal hose package length

All information relates to the total hose package length of the complete welding system and presents
exemplary configurations (of components of the EWM product portfolio with standard lengths). A straight
kink-free installation is to be ensured, taking into account the max. delivery height.
Pump: Pmax = 3,5 bar (0.35 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
Pump: Pmax = 4.5 bar (0.45 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
099-000237-EW501
25.04.2019
Hose package Wire feeder
(20 m / 65 ft.)
(25 m / 82 ft.)
(15 m / 49 ft.)
Hose package Wire feeder
(30 m / 98 ft.)
(40 m / 131 ft.)
(40 m / 131 ft.)
Temperature range
-10 °C to +40 °C (14 °F to +104 °F)
-20 °C to +30 °C (-4 °F to +86 °F)
miniDrive
(25 m / 82 ft.)
(10 m / 32 ft.)
miniDrive
(25 m / 82 ft.)
(25 m / 82 ft.)
Design and function
Transport and installation
Welding torch Max.
(5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
Welding torch Max.
(5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
30 m
98 ft.
30 m
98 ft.
40 m
131 ft.
45 m
147 ft.
70 m
229 ft.
