NAT/Route mode installation
Starting the setup wizard
Reconnecting to the web-based manager
Connecting the FortiGate unit to the network(s)
FortiGate-4000 Installation Guide
1
In the web-based manager, select Easy Setup Wizard.
Figure 24: Select the Easy Setup Wizard
2
Follow the instructions on the wizard pages and use the information that you gathered
in
Table 15 on page 48
3
Select the Next button to step through the wizard pages.
4
Confirm the configuration settings, and then select Finish and Close.
Note: If you use the setup wizard to configure internal server settings, the FortiGate unit adds
port forwarding virtual IPs and firewall policies for each server. For example, for each server
located on the Internal network the FortiGate unit adds an External->Internal firewall policy.
If you changed the IP address of the internal interface while you were using the setup
wizard, you must reconnect to the web-based manager using the new IP address.
Browse to https:// followed by the new IP address of the internal interface. The default
address of the internal interface is https://192.168.1.99.
The IP address of the out of band management interface is not changed from the
setup wizard. If you connected to the FortiGate unit using the out of band
management interface you do not have to reconnect after completing the wizard.
You are now finished the initial configuration of the FortiGate unit, and can proceed to
"Next steps" on page
After you complete the initial configuration, you can connect the FortiGate unit
between the internal network and the Internet.
•
To connect the FortiGate-4000P, see
page 28
•
To connect the FortiGate-4000S, see
page 29
and
Table 17 on page 54
56.
01-28004-0028-20040830
Connecting the FortiGate unit to the network(s)
to fill in the wizard fields.
"FortiGate-4000P network connections" on
"FortiGate-4000S network connections" on
55
