Using the web-based manager

Out of band management interface

Using the web-based manager
60
Table 18: Transparent mode settings
Administrator Password:
Management IP
DNS Settings
Use Table 19 to record the IP address, netmask, and default gateway of the
FortiGate-4000 out of band management interface if you are configuring this interface
during installation.
.
Table 19: Out of band management interface (Optional)
IP:
_____._____._____._____
Default Gateway: _____._____._____._____
You can use the web-based manager to complete the initial configuration of the
FortiGate unit. You can continue to use the web-based manager for all FortiGate unit
settings.
For information about connecting to the web-based manager, see
web-based manager" on page
The first time you connect to the FortiGate unit, it is configured to run in NAT/Route
mode.
To switch to Transparent mode using the web-based manager
1 Go to System > Status.
2 Select Change beside the Operation Mode.
3 Select Transparent in the Operation Mode list.
4 Select OK.
To reconnect to the web-based manager using the internal interface, change the IP
address of the management computer to 10.10.10.2. Connect to the internal interface
and browse to https:// followed by the Transparent mode management IP address.
The default FortiGate Transparent mode management IP address is 10.10.10.1.
IP:
Netmask:
Default Gateway:
The management IP address and netmask must be valid for the network
from which you will manage the FortiGate unit. Add a default gateway if the
FortiGate unit must connect to a router to reach the management
computer.
Primary DNS Server:
Secondary DNS Server: _____._____._____._____
34.
01-28004-0028-20040830
Transparent mode installation
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
Netmask:
_____._____._____._____
"Connecting to the
