Connecting to the web-based manager

Hot swapping the KVM switch module

Connecting to the web-based manager

Connecting to the FortiGate-4000 internal interface module

34
Follow this procedure to hot swap a KVM switch module.
For more information on the KVM switch module, see
page 19.
1 From the front panel of the FortiGate-4000 chassis, loosen the two mounting knots
that fasten the KVM switch module that you want to replace.
2 Pull out the KVM switch module.
3 Insert the new KVM switch module into the chassis.
4 Tighten the two mounting knots to fasten the KVM switch module to the chassis.
You can connect to the FortiGate-4000 web-based manager of each FortiGate-4000
unit installed in the FortiGate-4000 chassis by connecting to FortiGate-4000 internal
interface module or by connecting to the FortiGate-4000 10/100 out of band
management module.
Note: Each FortiBlade-4010 module is a FortiGate-4000 antivirus firewall.
To connect to the web-based manager you need:
• an ethernet connection between a management computer and the FortiGate-4000
unit.
• Internet Explorer version 4.0 or higher running on the management computer.
Note: You can use the web-based manager with recent versions of most popular web
browsers. The web-based manager is fully supported for Internet Explorer version 4.0 or higher.
• Connecting to the FortiGate-4000 internal interface module
• Connecting to the FortiGate-4000 10/100 out of band management module
• Connecting to the Command Line Interface (CLI)
To connect to the web-based manager of a FortiGate-4000 unit using the FortiGate-
4000 internal interface module, you must connect the FortiGate-4000 internal
interface module to the same network as your management computer.
01-28004-0028-20040830
Getting started
"KVM switch module" on
