Pass-Through Interface Module - Fortinet FortiGate FortiGate-4000 Installation Manual

Rear panel features

Pass-through interface module

24
Figure 11: 10/100 out of band management module
LAN 1
Mounting Knot
Table 8: 10/100 out of band management module LEDs
LED State
Amber
Interface LEDs Flashing
Amber
Green
Two pass-through interface modules are installed on the FortiGate-4000P. The
internal pass-through interface module connects to each FortiBlade-4010 internal
interface. The external pass-through interface connects to each FortiBlade-4010
external interface. Each pass-through interface module contains ten gigabit copper
ethernet interfaces, one for each FortiBlade-4010 module.
Figure 12 shows the connections between the pass-through interface module
ethernet connectors and the FortiBlade-4010 modules installed in the FortiGate-4000
chassis. The connections are arranged the same on the internal and external pass-
through interface modules.
Figure 12: Pass-through interface module showing interface correspondence
1
KVM/ACCESS
PWR/KVM STATUS
LAN 1 LAN 2
POWER ON/OFF
Pass-through interface module
LAN 10 LAN 9
10 9
Mounting Knot
01-28004-0028-20040830
LAN 2
LAN 1 LAN 2
Description
The correct cable is in use and the connected equipment has
power.
Network activity at this interface.
The interface is connected at 100 Mbps.
Slot number
2 3 4 5
KVM/ACCESS KVM ACCESS KVM/ACCESS KVM/ACCESS
PWR/KVM STATUS PWR/KVM STATUS PWR/KVM STATUS PWR/KVM STATUS
LAN 1 LAN 2 LAN 1 LAN 2 LAN 1 LAN 2 LAN 1 LAN 2
POWER ON/OFF POWER ON/OFF POWER ON/OFF POWER ON/OFF
LAN 8 LAN 7 LAN 6 LAN 5 LAN 4
8 7 6 5 4
LAN interface number
6 7 8 9
KVM/ACCESS KVM/ACCESS KVM/ACCESS KVM/ACCESS
PWR/KVM STATUS PWR/KVM STATUS PWR/KVM STATUS PWR/KVM STATUS
LAN 1 LAN 2 LAN 1 LAN 2 LAN 1 LAN 2 LAN 1 LAN 2
POWER ON/OFF POWER ON/OFF POWER ON/OFF POWER ON/OFF
LAN 3 LAN 2 LAN 1
3 2 1
Mounting Knot
Getting started
Mounting Knot
10
ALARM
KVM
KVM/ACCESS
PWR/KVM STATUS
LAN 1 LAN 2
POWER ON/OFF
Fortinet Inc.
