Switch
UPS or bypass output can be selected by this switch.
AC Output Breaker
This circuit breaker marked with "OUTPUT'' is a resettable protective thermal circuit breaker to protect the
output from overloads and short circuits.
AC Input Breaker
This circuit breaker marked with "UPS INPUT'' provides input power protection for the UPS.
AC Output Receptacles
These receptacles are ready to use for optional battery heating pads or a PC for maintenance.
UPS Input Connector
This "UPS IN" power cord is connected to AC input connector or terminal blocks on UPS.
UPS Output Connector
This "UPS OUT" power cord is connected to the AC output connector or terminal blocks on UPS.
PTS Control Wiring
The Black and Red PTS control wires are used to connect to PTS control connector on UPS.
