PROLiNK PRO2000LD User Manual page 13

5.5.3 LCD Menu Tree
Users can check the status, view event log, set parameters and control of UPS via LCD panel. See below Menu
Tree.
Status Menu
1. Serial No.
xxxxxxxxxxxxxx
2. I/P-V:
xxx.xV
3. I/P-F:
xx.xHz
4. BAT V: xx.x V ▼
5. BAT T:
xx°C
6. O/P-V: x
xx.x V
7. O/P-F: xx.xHz
8. O/P-P: xxxxVA▼
9. O/P-P: xxxxWatt
10. Load: x
xx%
11. Mode: xxxxx
12. InvEV: xxxxx▼
13. InvTM: xxxx.xH
14. BukEV: xxxxx
15. BukTM: xxxx.xH
16. BstEV: xxxxx
17. BstTM: xxxx.xH
18. C1:Off(or On) C2:Off(or On)
19. C3:Off(or On) C4:Off(or On)
20. C5:Off(or On) C6:Off(or On)
21. : xx.xx
MainFW
22. : xx.xx
LCDFW
23. HW : xx.xx
▼
► 1. Active Log
2. History Log
Active
Event
yy-mm-dd hh:mm
Over Load
In xxxxxx Mode
xx/xx
yy-mm-dd hh:mm
Site fault
In xxxxxx Mode
xx/xx
yy-mm-dd hh:mm
Over Load
In xxxxxx Mode
xx/xx
▼
yy-mm-dd hh:mm
Site fault
In xxxxxx Mode
xx/xx
▲
Figure 9: LCD Menu Tree
Startup
......
After 6sec, enter default page
yy-mm-dd hh:mm
Mode: xxxxx
OP-V: xxx.xV
Load : xxx%
Esc
Enter
► 1. Status ▼
2. Event log
3. Setting
4. Control
5. Help
▲
Event Menu
History
Event
History Event
► 1. Inquiry
2. Clear
▼
Show all
current event
▲
Clear all
history event?
Yes
⊙
▼
No
○
All history event
deleted !
▲
Show all history event
200 log maximum
11
Power on
automatically.
Default page
Menu page
Settings&
Control Menu
Enter password :
****
Setting Control
menu menu
Default Password: 1111
Help
UPS-2000A
