Parameter Descriptions Table (All levels are user-programmable. Some values are interdependent.
50. Buck Function
51. Boost Function
52. Sense Type
53. Line Qualify Time
54. Line High
When input voltage exceeds this level, unit transfers
to Battery Mode from either Buck Mode (when AVR is
enabled) or Line mode.
55. Line Low
When input voltage is lower than this level, unit
transfers to Battery Mode from either Boost Mode
(when AVR is enabled) or Line Mode.
56. Boost Low
When input voltage drops between Boost Back point
and Boost Low point, unit will transfer to Boost Mode
only when AVR is enabled.
57. Buck High
When input voltage increases between Buck High
point and Buck Back point, unit will transfer to Buck
Mode only when AVR is enabled.
58. High Gap
59. Low Gap
* High Back
When input voltage drops below this level, unit
transfers back to Line Mode from Battery Mode.
* Low Back
When input voltage rises above this level, unit
transfers back to the Line Mode from Battery Mode.
* Boost Back
When input voltage rises above this level, unit
transfers to Normal Mode.
* Buck Back
When input voltage drops below this level, unit
transfers back to the Normal Mode.
AVR Function Disable
Default Setting Selections or
Normal
Battery to Line 30s
--------------------
130VAC
or
Line to Battery 260VAC
--------------------
100VAC
Line to Battery or
-------------------- 200Vac
[DISABLE]
Normal to Boost
--------------------
Normal to Buck [DISABLE]
--------------------
5VAC
or
10VAC
5VAC
or
10VAC
Battery to Line
-------------------- ( Line High - High Gap )
Battery to Line
-------------------- ( Line Low + Low Gap )
Boost to Normal
-------------------- [DISABLE]
Buck to Normal
-------------------- [DISABLE]
27
AVR Function Enable
Default Setting Selections or
Selectable
Range
√
√
Normal Normal Normal
Generator Generator
3s 30s 3s
10s 10s
30s 30s
120~152VAC 152VAC 120~152VAC
or or
241~300VAC 300VAC 241~300VAC
90~120VAC 88VAC
or or
176~240VAC 176VAC 176~240VAC
102VAC
or
216VAC
128VAC 120~144VAC
or
264VAC 241~288VAC
3~7VAC 5VAC
or or
6~14VAC 10VAC
3~7VAC 5VAC
or or
6~14VAC 10VAC
( Line High - High Gap )
( Line Low + Low Gap )
( Boost Low + Low Gap )
( Buck High - High Gap )
Selectable
Range
or
90~120VAC
or
96~120VAC
or
192~240Vac
or
3~7VAC
or
6~14VAC
3~7VAC
or
6~14VAC
