5.6.4 RS232/USB Main Menu
The RS232 / USB menus are hierarchical. Press ENTER to access main menu as shown in Figure 20. Type in the
number of submenu and press Enter button to access a particular submenu. Press Enter to refresh the screen,
the Status, Faults, and Alarms readouts.
Note: It's requested to enter passwords in 8 Login Administrator first to access submenu 3~7. The factory
default password is 1111.
The main menu displays the submenu numbers, the line status, the unit's output status and any faults or alarms
that may be present.
UPS Model:
ID: 92611310100001
[0-MAIN MENU]
1 Unit Specification
2 Input / Output Values
3 Control
4 System Setting
5 Line Conditioning Setup
6 Programmable Contacts Setup
7 Event Log View
8 Login Administrator
Date & Time
Sense Type
Line Status
Output Status : Inverter
Contact Status :
Contact C1 ==> [ON BATT]/[Activated]
Contact C2 ==> [ON BATT]/[Activated]
Contact C3 ==> [LOW BATT : 46.0 Volts]/[Not Activated]
Contact C4 ==> [LOW BATT : 46.0 Volts]/[Not Activated]
Contact C5 ==> [Timer : 2.00 Hours]/[Not Activated]
Contact C6 ==> [Timer : 2.00 Hours]/[Not Activated]
Ext.Fan Status : [Activated]
Faults : None
Alarms : Line Fail/BTS Disconnect
: 13-10-14, 09:24:02
: [Normal]
: Not Good
Figure 20: Main Menu Screen
