PROLiNK PRO2000LD User Manual page 26

5.6.5 Unit Specifications
To access Unit Specification menu, type 1 and press Enter on the main menu. To return to the main menu,
press Esc and then press Enter buttons.
It lists unit specifications as following table.
Unit Model
Unit Freq
Input Voltage
Output Voltage
Output VA
Battery Voltage
Max Charge Current
Panel Firmware Version
Main Firmware Version
Hardware Version
5.6.6 Input/Output Values
To access Input/Output Values menu, type 2 and press Enter on the main menu. To return to the main menu,
press Esc and then press Enter buttons.
Following table lists the actual measurements of input / output parameters.
Input
Voltage
Freq
Output
Voltage
Freq
Power
VA
Load Per
Battery
Temperature
Voltage
Evt-Timer
INV Event
INV Timer
BUCK Event
BUCK Timer
BOOST Event
BOOST Timer
[ 1 - Unit Specifications ]
The model name
Nominal operating frequency
Nominal input voltage
Nominal output voltage
The output capacity in VA
Nominal battery voltage
Maximum charging current
Panel board firmware version
Main board firmware version
Hardware version
[ 2 – Input / Output Values ]
The Input voltage
The Input frequency
The output voltage
The output frequency
The output active power
The output apparent power
The load percent of output power
The ambient temperature of the battery case as read via attached temperature
probe.
The battery DC voltage
The number of times that input power failure occurs
Total time that the battery was discharged since the latest RESET
The number of times that BUCK function activates
Total time that the BUCK function activates since the latest RESET
The number of times that BOOST function activates
Total time that the BOOST function activates since the latest RESET
24
