Summary of Contents for PROLiNK EnerHome PRO PRO700
- Page 2 Blk 16 Kallang Place #06-02 Singapore 339156...
- Page 3 1. CAUTION English The UPS battery has been fully charged before leaving our factory. During the shipment, some level of power may have been discharged. In order to ensure the efficiency of the UPS, please allow the UPS to charge its battery for at least 12 hours before use. Connect the UPS to a two-pole, three-wire grounding mains (AC).
-
Page 4: Operation
2. OPERATION 2.1 Operating Instructions Connect the AC input power cable of your UPS to the AC Power. ‘YELLOW’ LED on the UPS front panel is lit. UPS is charging the battery. (Note: DO NOT connect any load to your UPS until the UPS has charged its battery for 12 hours) Plug computer and monitor to UPS sockets. -
Page 5: Front / Rear Panel Explanation
2.3 Front / Rear Panel Explanation Yellow LED ON when UPS is offline charging battery. Blinking when AC is abnormal. Green LED ON when UPS is running normal. OFF when UPS is off or abnormal. Red LED : On only when UPS is fault MAIN Switch : Control UPS On/Off . -
Page 6: Specifications
3. SPECIFICATIONS Model PRO700 Capacity 650VA Input Voltage Range 140 – 300VAC ± 5VAC Frequency > 40 Hz Phase Single + GND Output Voltage Range 230VAC + 11% - 17% Battery Mode 230VAC ± 10% Frequency 50Hz ± 1Hz (Battery Mode) Simulated Sine Wave (Battery Mode) Waveform Sine Wave (AC Mode) -
Page 7: Bahasa Indonesia
1. PERHATIAN Bahasa Indonesia Baterei UPS sudah diisi penuh sebelum keluar dari pabrik. Selama pengiriman, kapasitas dari isi baterei akan berkurang. Untuk memastikan efisiensi dari UPS, sebaiknya baterei diisi kembali sebelum digunakan selama 12 jam. Hubungkan UPS ke pusat listrik dengan menggunakan kabel 3 pin (berikut grounding). Grounding ini sangat berguna untuk memproteksi peralatan kita dari petir. -
Page 8: Instruksi Penggunaan
2. PENGGUNAAN 2.1 Instruksi Penggunaan Sambungkan kabel power dari UPS ke sumber listrik (PLN). Lampu ‘KUNING’ akan menyala. Artinya UPS sedang melakukan charging ke baterai. (Note: JANGAN dulu menggunakan UPS anda sampai baterai dari UPS anda sudah di charge selama kurang lebih 12 jam). -
Page 9: Permasalahan Dan Solusi
2.3 Penjelasan Panel Depan Lampu KUNING HIDUP ketika UPS sedang melakukan Proses charging BERKEDIP ketika sumber listrik (PLN) padam Lampu HIJAU HIDUP ketika UPS bekerja normal. MATI ketika UPS mati atau tidak normal. Lampu MERAH HIDUP UPS overload, atau bermasalah MAIN Switch Untuk mengontrol UPS HIDUP / MATI . - Page 10 3. SPECIFICATIONS Model PRO700 Capacity 650VA Input Voltage Range 140 – 300VAC ± 5VAC Frequency > 40 Hz Phase Single + GND Output Voltage Range 230VAC + 11% - 17% Battery Mode 230VAC ± 10% Frequency 50Hz ± 1Hz (Battery Mode) Simulated Sine Wave (Battery Mode) Waveform Sine Wave (AC Mode)
-
Page 11: Technical Support
Blk 16 Kallang Place #06-02 Kallang Basin Industrial Estate Singapore 339156 Malaysia FIDA SYSTEMS (M) SDN BHD 29 USJ 1/31, 47600 Subang Jaya Selangor, Darul Ehsan, Malaysia Indonesia PROLiNK INDONESIA P.Jayakarta Komplek 85 BR/AJ, Jakarta Pusat, Indonesia ONLINE TECHNICAL SUPPORT: support@fida.com... - Page 12 2009 Fida International (S) Pte Ltd. Version 1.0 (Jul’09). PROLiNK is a trademark of Fida International (S) Pte Ltd and is manufactured under its authority. All other brands, products, services, logos and company names mentioned herein are trademarks of their respective owners.
