BEFORE GETTING STARTED
This document is designed to aid you to get started with the device. If you experience problems following these
guides or need further information pertaining to the device, please visit our website at www.prolink2u.com.
All specifications are subject to the manufacturer's configuration at the time of shipping and may change
without prior notice, written or otherwise.
PRO1200SFT/SFTU
Quick Start Guide
MODEL NO:
PRO700SFT/SFTU
PRO850SFTU
Line Interactive UPS
Version 1.00
(English / Indonesian)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO700SFT and is the answer not in the manual?

Questions and answers

Related Manuals for PROLiNK PRO700SFT

Summary of Contents for PROLiNK PRO700SFT

  • Page 1 MODEL NO: PRO700SFT/SFTU PRO850SFTU PRO1200SFT/SFTU Quick Start Guide Line Interactive UPS Version 1.00 (English / Indonesian) BEFORE GETTING STARTED This document is designed to aid you to get started with the device. If you experience problems following these guides or need further information pertaining to the device, please visit our website at www.prolink2u.com.

  • Page 2: Important Safety Warning

    1. Important Safety Warning CAUTION: To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area free of conductive contaminants. (See the specifications for the acceptable temperature and humidity range.) To reduce the risk of overheating the UPS, DO NOT cover the UPS' cooling vents and avoid exposing the unit to direct sunlight or installing the unit near heat emitting appliances such as space heaters or furnaces.

  • Page 3: Package Contents

    One (1) piece of Quick Start Guide Note: If any of above item is not packed in your package when open, please consult your reseller immediately. 3. Product Overview PRO700SFT/PRO700SFTU Legend: LCD display (Refer to LCD Operation for details) Power Switch...
  • Page 4 PRO1200SFT/PRO1200SFTU Front View Rear View Legend: LCD display RJ45/RJ11 Ports (Refer to LCD Operation for details) AC Input Power Switch Output receptacles USB port (only applicable for SFTU model) EN 3...

  • Page 5: Installation & Initial Startup

    4. Installation & Initial Startup Note: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Connect to Utility and Charging Plug in the AC input cord to the wall outlet. For the best results, suggest to charge the battery at least 6 hours before initial use.

  • Page 6: Lcd Operation

    5. LCD Operation UPS Mode Description UPS Power on When UPS is powered on, it will enter this mode for few seconds. Standby Mode Only input voltage is disp layed even LCD is touched again. AC Mode LCD information will be displayed in the following order when LCD is touched.

  • Page 7: Troubleshooting

    Software Download & Installation Please follow steps below to download and install monitoring software: Go to the website http://www.power-software-download.com Click ViewPower software icon and then choose your required OS to download the software. Follow the on-screen instructions to install the software. When your computer restarts, the monitoring software will appear as an orange plug icon located in the system tray, near the clock.

  • Page 8: Fault Code

    8. Fault Code Fault condition Solutions Disconnect short-circuited loads Output short circuited and restart the UPS again. Disconnect all output loads and Overload fault restart the UPS again. Call for service immediately. Overcharge Please replace the battery. Bad or severely discharged battery Call for service immediately.

  • Page 9: Specifications

    9. Specifications Model PRO700SFT/SFTU PRO850 SFTU PRO1200SFT/SFTU CAPACITY 650 VA 850 VA 1200 VA INPUT Voltage 230 VAC Voltage Range 140~ 300 VAC Frequency Range 50/60Hz (Auto sensing) OUTPUT Voltage Regulation +/ -10% (batt mode) Frequency Range 50 or 60 Hz +/ -1 Hz...
  • Page 10 1. Peringatan Penting Keselamatan PERHATIAN: Untuk mencegah resiko kebakaran atau sengatan listrik, pasang pada daerah yang suhu dan kelembabannya terkontrol (Lihat spesifikasi untuk rentang suhu dan kelembaban yang ditentukan.) Untuk mengurangi resiko overheating dari UPS, JANGAN menutup ventilasi UPS dan menempatkan pada daerah yang terkena sinar matahari langsung atau menempatkan dekat dengan peralatan yang memancarkan panas.
  • Page 11 Satu (1) piece Lembar Panduan Singkat Catatan: Jika salah satu item di atas tidak dikemas dalam paket anda ketika terbuka, silakan, berkonsultasi dengan reseller anda segera. 3. Ikhtisar PRO700SFT/PRO700SFTU Legend: LCD display (Refer to LCD Operation for details) Power Switch...
  • Page 12 PRO1200SFT/PRO1200SFTU Front View Rear View Legend: LCD display RJ45/RJ11 Ports (Refer to LCD Operation for details) AC Input Power Switch Output receptacles USB port (hanya untuk SFTU model) ID 3...
  • Page 13 4. Instalasi Dan Sebelum Memulai Catatan: Sebelum melakukan instalasi, mohon unit diperiksa. Pastikan tidak ada yang rusak didalam kemasan. Sambungkan ke Listrik dan Charging Sambungkan kabel power ke sumber listrik. Untuk hasil yang terbaik, disarankan untuk mencharge baterai minimal 6 jam sebelum digunakan.
  • Page 14 5. LCD Operation UPS Mode Description UPS Power on When UPS is powered on, it will enter this mode for few seconds. Standby Mode Only input voltage is disp layed even LCD is touched again. AC Mode LCD information will be displayed in the following order when LCD is touched.
  • Page 15 Software Download & Instalasi Please follow steps below to download and install monitoring software: Go to the website http://www.power-software-download.com Click ViewPower software icon and then choose your required OS to download the software. Follow the on-screen instructions to install the software. When your computer restarts, the monitoring software will appear as an orange plug icon located in the system tray, near the clock.
  • Page 16 8. Fault Code Fault condition Solutions Disconnect short-circuited loads Output short circuited and restart the UPS again. Disconnect all output loads and Overload fault restart the UPS again. Call for service immediately. Overcharge Please replace the battery. Bad or severely discharged battery Call for service immediately.
  • Page 17 9. Spesi kasi Model PRO700SFT/SFTU PRO850 SFTU PRO1200SFT/SFTU CAPACITY 650 VA 850 VA 1200 VA INPUT Voltage 230 VAC Voltage Range 140~ 300 VAC Frequency Range 50/60Hz (Auto sensing) OUTPUT Voltage Regulation +/ -10% (batt mode) Frequency Range 50 or 60 Hz +/ -1 Hz...
  • Page 18 Register Online For Your Product Warranty @ www.prolink2u.com/register PROLiNK® is a trademark of FIDA INTERNATIONAL (S) PTE LTD and is manufactured under its authority. All other brands, products, services, logos and company names mentioned herein are trademarks of their respective owners. All specifications, designs and contents are subject to changes without prior...
