Labnet MultiGene OptiMax TC9610 Operation Manual page 7

MultiGene Thermal Cycler
Name Function
Function Keys Use the function keys (F1 to F5) to activate the "button" displayed on
the screen above the key; for example, F1 for RUN.
(F1 to F5)
The four Directional Arrow keys can move the cursor into different
Directional
directions.
Arrow Keys
ENTER key The current selection is activated or accepted when the ENTER key is
pressed.
The alphanumeric keys are usually used as number keys for the entry
Alphanumeric
of time, temperature, password and cycle numbers. When entering a
Keys (0~9)
user name or protocol name, a small screen will pop out to display the
letters after pressing the Alphanumeric keys. Press the selected key
until the desired letter is highlighted. Press the ENTER key to select
the letter or wait 5 seconds.
CLEAR key Press CLEAR key will erase the entry in an input field.
(CE)
By pressing STOP, the Protocol current running will be terminated.
STOP key
Figure 1. Front Panel Overview
3
