Box Holders With Clamps; Box Holder - Adjustable (Selfra/Selfsra) - logitrans ROTATOR SELFR Manual

A
2.0 Functions and identifications

2.2 Box holders with clamps

If the box can fall off, or if it has to be tilted more than 60º, box holders with clamps
have to be used.
Box holders with clamps can grip, hold and rotate boxes with different heights.
The clamps are to be tightened when the box is lifted from the floor.
Box holder with clamps Box holder with clamps
– upper position – lower position

2.3 Box holder - adjustable (SELFRA/SELFSRA)

If handling boxes with different widths, Rotator can be provided with adjustable box
holders.
Using the handle (A), adjust the width of the box holders to fit different box widths
(between 800 mm and 1200 mm).
A
7
